News from the lab!

•July 13, 2009 • 1 Comment

There’s been a bit of a lag in posts lately for a good reason.  I just have to come up with it quick.  Thinking…thinking…

Oh yeah, I’ve been busy.  Really busy.  There you go.

I tend to get sucked in to projects and disappear into the lab for months at a time.  Ask around.  Go on.  It’s a vicious cycle, really.  Because I’m always in the middle of one project or the other, this should come as no surprise.  But this one…this is a project I’ve been working on for years now.

If you go back far enough you can find DARN.  Slightly less far back is a post involving DARN and frequency analysis.  Now I’m preparing for the next iteration.  The biggest change is a surprise, but something that will make this version better than ever.  The pressure, temperature, accelerometer, and gauss meter are already sussed, but the EMF/dynamic magnetic field /magnetic flux sensor is becoming quite troublesome.  Ever try to filter and amplify something that’s between 1-200uV, in the low frequency range, and with a .6V DC component?  It’s all fine and dandy until you replace the ideal op-amp model with the gritty real world.

Then things get really fun.

On the previous versions, I just modified this rather swell design to suit my needs:

http://www.zen22142.zen.co.uk/Circuits/Misc/emf.htm

But my inductors were always hand-wound and, frankly, horribly unappealing in terms of aesthetics.  And because of their homemade nature, each varied wildly causing me to calibrate each sensor in software.  While it worked for the last two models, I’m hoping for a bit more consistency this time around.  And…well, I’m out of old ferrite antennas.  Ehrm.  As such, I decided to take the inductor out of the equation entirely and try rocking this little guy:

http://www.sparkfun.com/commerce/product_info.php?products_id=708

Which, as you might imagine, is proving quite the headache.  Even with multiple gain/HP filtering stages, it’s getting a bit dicey.  I suppose that’s why there’s a lack of schematics featuring them in an ‘EMF’ meter design.  Nothing worth doing is ever easy.

Drat.

Back to work I go!

–Josh

Java, Speech, and inspiration…

•April 20, 2009 • 7 Comments

I’ve been getting poked and prodded to keep this site somewhat updated, so I thought I’d share my experience over Christmas and New Years…and prove beyond a doubt that I truly need to get out more.

First the Java part of things.  This was my very first programming language–even before HTML, oddly enough.  I needed to turn an EE class into an honors credit (back when I was still in the Schreyer’s Honors College, mind you) and the professor agreed on the condition that I worked within a group to write a Java applet.  Somehow or other, I ended up doing the coding (despite the fact that my other two cohorts were Computer Science majors or Computer Engineers at that current time.)  Mike Mansell rewrote my code into something vaguely resembling humorous English and Emrys Smith ended up doing the PowerPoint.  Care to see it?

http://www.personal.psu.edu/ked2/CSE/Conversion.html

Pretty boring, right?  As I said, that was my first program and it taught me quite a bit.  But that was the last time I used Java…

…until just a few months ago.  I got it into my head that I wanted to do something involving Speech Control.  And I wanted something that I could toss onto any system from XP to Ubuntu (to be fair those are the only two OSes I use on a regular basis.)  Also, I didn’t want to have to upgrade to Vista just to get a taste of SAPI 5.3.  I was well aware of CMU’s Sphinx and its numerous variants, so I started out with that.  To put it mildly, it isn’t really for a novice in Java programming.  To put it realistically, I spent a week trying to get a GUI to work with it before abandoning it in favour of a third party interface that utilized the Sphinx speech recognition engine.  Then I tried both Julius and Simon, but they just weren’t what I was looking for.  Then I found Voce.  Using the sample code, I was able get a custom GUI up and running in about ten days with it understanding a dozen words clearly. In fact, the moment of my first breakthrough happened at about 1am on New Years Day.  Note to self, try to get out of house next year.  Then within three days, I had it outputting through a serial port for real world applications.

This is where things could get interesting–or fail disastrously.  My original notion was to create a speech controlled robotic arm with a camera end effector to document my projects.  “Left, Down, Cheese, *Click*.  You get the picture.  But as it turns out, robot arms don’t grow on trees and good robot arms are even more difficult to come by.  And I’ve got to say, the whole “Lights on, Lights off” bit gets rather boring if not outright cumbersome.  “Sarah, beer (coffee) me” (a la Eureka) has its appeal, but even that would get a touch dull.  Without a clear idea of what to do now that I’ve gotten so far along on the project, I’ve just been waiting for these past three months for a moment of inspiration.  But it appears that my muse is off on hiatus.  So I’m reaching out to anyone reading this entry to toss up your suggestions in the comments section.  It’s got to have some form of physical payoff, opening programs on the computer is just too easy. And it should be rather nifty or why do it at all?

Related links:

http://cmusphinx.sourceforge.net/html/cmusphinx.php

http://sourceforge.net/projects/speech2text/

http://julius.sourceforge.jp/en_index.php

http://voce.sourceforge.net/

EMF in Theory and Practice: Part II

•February 28, 2009 • Leave a Comment

EMF in Theory and Practice: Part II


In the first part of this series of articles, I posited the ‘why’ of bringing along an EMF meter on an investigation. To concisely summarize the previous results: because they measure electromagnetic fields, of course. What I neglected to mention was the ‘how’ of the matter. Now I plan to take some of the mystery out of the magnetic field—or at least its measurement. Let’s take it from the top, shall we?

Any basic physics book will inform you that EMF refers to the electromotive force. That is just an archaic title for the voltage from a given electrical source—such as a battery. However, for the paranormal community (and likely the contracting and electrical communities), EMF has come to be associated with electromagnetic fields. And for a very good reason: it requires less than half the syllables to say. So we will follow that nomenclature for this article. And what is an electromagnetic field? An EMF is established whenever current flows through a conductor. It’s as simple (or complex) as that. Most often this occurs in standard household wiring, but also transpires every time lightning strikes.

Following that, inversely, if a magnetic field is varying in time it will induce a current through a coil. This is how the standard single/tri-coil EMF meters operate. To see this in action, simply plug in a dynamic microphone and place it in close proximity to active AC wiring. Provided that microphone/soundcard/amplifier does not filter out 60Hz (or 50Hz) you should hear a low frequency hum. Congratulations, you have just made a rudimentary EMF detector. This works due to the EMF inducing a current in the wire coil of this variety of microphone and subsequently generating a voltage. Notice that (for a straight wire instance) the EMF is at a maximum amplitude perpendicular to the AC wiring and by adjusting the angle of the microphone relative to the wiring the ‘volume’ rises and falls. This is where tri-coil/tri-field meters have the advantage—proper alignment is less of an issue.

Similar in principal to the coil EMF detector is the fluxgate magnetometer. Put the coil in the aforementioned design onto a ferrous toroid (a doughnut shaped piece of magnetically ‘conductive’ material.) To this, add another coil and attach this to DC voltage source. This will create a coupled magnetic field between the two coils. Provided that the ferrite core is not operating near saturation (the point at which an increase in coil magnetic field yields limited increase in the overall system) the coil on the reception side will be able to read in a much weaker EMF. The main drawback to both of these setups is that unless the magnetic field is varying in time, they are incapable of perceiving it. One method of discovering a potential DC source is to vary the field spatially over time. Yes, just move the meter back and forth repeatedly at a vigorous rate (of course, do not neglect the force of acceleration acting upon on analogue meter…and moving the needle.) Of course there is a more elegant solution to this.

A gauss meter detects both AC and DC magnetic fields. It does this by relying on a linear Hall or other magnetic field sensing semiconductor technology. The solid state semiconductor physics behind a hall-effect sensor are beyond the scope of this article. But the gist of the matter is that when a magnetic field is applied to a piece of specially treated semiconductor material, it allows a current to flow. If the voltage is proportional to the magnetic field intensity, you have a linear hall-effect sensor that can be calibrated to register the precise field amplitude. Other examples simply switch on and off over a certain range of field intensity. The magnetic sensors utilized for security door alarms function in this manner.

Gauss meters are effective for both DC and AC fields so they should be used in conjunction with EMF meter. If the gauss meter goes off while the EMF meter is steady, it implies one of two things: either the field is nearly static (DC) or the field is varying at a rate that is much higher than the EMF meter is intended to operate and is filtered out. Remember that most EMF meters are designed for operation at 60Hz, although models vary greatly. If your EMF meter has a relatively wide frequency response, it likely indicates a DC field. What does a DC field indicate in the paranormal? Not much as far as the spirits and hallucination-inducing time-varying magnetic-fields are concerned. Perhaps the UFO community can point me towards a suggestion.

Additional References:

http://www.who.int/peh-emf/about/WhatisEMF/en/

http://www.zen22142.zen.co.uk/Circuits/Misc/emf.htm

http://www.zen22142.zen.co.uk/Circuits/Testgear/emmeter.htm

http://www.physics.uq.edu.au/people/ficek/pdfs/ph3050.pdf

http://hyperphysics.phy-astr.gsu.edu/hbase/magnetic/hall.html

http://micro.magnet.fsu.edu/electromag/java/faraday2/

EMF in Theory and Practice: Part I

•February 28, 2009 • Leave a Comment

EMF in Theory and Practice: Part I


In the palms of paranormal enthusiasts worldwide lies a small, unassuming, handheld device. Innocuous as it appears, still the apparatus is able to render the invisible into a physical form. In a typical scenario, this tool is affixed to an investigator for hours on end while the individual walks the ground of a haunted locale. At some point, the needle swings wildly to indicate an unseen force, whereupon the handler informs his or her colleagues. This is something that has played out in countless television shows and documentaries. What is often glossed over is a simple question: why?

Despite its ubiquity in the field, there is little evidence to support the effectiveness of an EMF meter in detecting the presence of an entity. Without conclusive evidence, why carry such an instrument along on an investigation? Because its efficacy has been thoroughly tested in what it was intended to measure: an electromagnetic field. And while the connection between an entity and an electromagnetic field remains dubious, the connection between an EMF and the human brain is somewhat more established.

Let’s start with some basic physics. Every time current flows through a wire, an electromagnetic field is established. Conversely, a time-varying electromagnetic field induces a current in a wire proportional to the field intensity, distance, and angle. Now simply replace the wire with a brain. It may be a messy substitution, but it is a necessary one. It is when a current is induced within the brain that matters truly begin to get interesting.

TMS (transcranial magnetic stimulation) relies on a single, somewhat intense electromagnetic pulse (.5 Tesla at the affected area).  As you might have guessed from the name, by performing tMS multiple times per second you generate the repetitive form or rtMS—a technique that is gaining popularity in a number of different areas.   rtMS is being utilized as an alternative to electroconvulsive therapy in severe depression and as an additional treatment in schizophrenia and migraines.  In terms of cognitive augmentation, this technology is also being used to induce the heightened thinking of savantism and to halve the hours of required sleep.

Interesting as that may be, you may be questioning what tMS has to do with the paranormal. Let’s turn our attention to the work of Michael Persinger.  One of his numerous claims to fame is ‘The God Helmet,’ also known as the Koren Helmet and marketed by Todd Murphy as the Shakti.  The helmet contains pairings of magnetic coils that are connected to a computer sound card while a computer is playing a specific sequence of pulses.  The coils generate a weak magnetic field (on the order of one microTesla) and it is the same rtMS result as before with one significant difference.  The end result is the sensation of a paranormal event—the most significant of which is the feeling of an unseen entity in the subject’s presence.

Does this invalidate the experience of innumerable people? I do not believe so. At least no more so than applying an electrode to a brain in order to induce the smell of roses disproves the existence of roses. However, this is precisely why an EMF meter is necessary in the arsenal of the investigator: to eliminate problems triggered by a far more mundane source.

Additional References:
http://en.wikipedia.org/wiki/Transcranial_magnetic_stimulation
http://www.sciencedirect.com/science?_ob=ArticleURL&_udi=B6T4S-4NYSHDB-1&_user=10&_coverDate=12/01/2007&_rdoc=1&_fmt=&_orig=search&_sort=d&view=c&_acct=C000050221&_version=1&_urlVersion=0&_userid=10&md5=51cca1d2698db7580e7ebfd6b31900a9
http://www.sciencenews.org/articles/20000923/bob10.asp
http://www.webmd.com/migraines-headaches/news/20060622/pulse-away-migraine-pain?page=2
http://www.nytimes.com/2003/06/22/magazine/22SAVANT.html?pagewanted=1&ei=5007&en=0497e5b30fc4a9d8&ex=1371614400&partner=USERLAND
http://discovermagazine.com/2007/aug/tms-sleep
http://www.wired.com/wired/archive/7.11/persinger.html
http://www.shaktitechnology.com/

Motion Detection

•February 28, 2009 • 2 Comments

Motion Detection, Cold Spots, and “What-was-that?”


Some time has passed since the airing of the “Dark Man” case and I have been wandering at the lack of inquiry regarding the motion detectors. The very absence of questioning is in itself somewhat perplexing, actually. Given that I still want to discuss a few points, I suppose I shall have to question myself.

Let’s tackle the most obvious question first. “Do ghosts have enough density to set off motion detectors?” I haven’t the foggiest idea. But that’s fine, because motion detectors, generally speaking, do not actually track motion. There are two principal categories of typical sensor-based motion detectors—ultrasonic and PIR. The ultrasonic version sends out a high frequency pulse, counts how long it takes to receive the echo, and then looks for a change in duration. Interesting, although it is not without flaws. For example, the sensor requires the echo to hit something solid—and the average ghost tends not to be. This is where a PIR sensor has the upper hand.

A PIR (passive infrared) motion detector uses a pyroelectric sensor, which is sensitive to wavelengths from 5-15 micrometers (µm) or roughly -80°C-306.45°C—likely with some attenuation at the extremes. Body temperature is typically 9.340 µm, just for reference. This is sent through a low pass filter followed by a differentiator and comparator. The low pass filter removes high frequency noise, the differentiator looks for changes in the sensor output over time, and the comparator checks to see if enough of a change took place for, say, a light to turn on. How long a given output (the light in this case) is on varies with the timing side of the circuit (monostable multivibrators vs. RC timers.) In any case, timing is irrelevant. We’re interested in what the PIR can detect.

In the Dark Man case (the first time we had employed motion detectors), the objective was not to determine whether there was motion. Rather there was a need for determining whether the temperature changed. Yes, the motion detectors were used as low-budget, rudimentary thermal cameras. All in all, a fairly practical cold-spot alert system—provided a camera was trained upon the units’ perspective. More on that shortly.

Of course, that is based upon the theory that entities actually create areas of cold or hot air. And it is just that: a theory. The second use for the motion detector is precisely what it was intended for: tracking people or animals. For example, a motion detector going off may indicate a person located in an area thought to be vacated and save an interruption later during a critical part of the investigation. Animals…well the obvious reason would be keeping track of house pets that cause poltergeist-esque destruction and disarray. Less obvious is drawing attention to the almost unseen mice caught on the camera that are the cause of the sound of scratching within the walls. A bright light is easier to monitor than a small dark gray blob streaking across the floor.

With the why and how out of the way, let’s turn to the practical side of the matter. How do you put one together and set it up? The easiest way is to track down a battery operated module. Failing that, the next best thing is to find a PIR security light from a home improvement store and wire it with an appropriate replacement cord (two or three prong depending upon the light) and affix the unit to a platform (i.e. a piece of wood.) Of course, building one runs the risk of electrocution, fire hazards, and headaches from troubleshooting. I assume no responsibility, sorry folks. Given that, unless you know what you are doing, please locate a battery powered unit.

Get to know your motion detector. Take some time before an investigation to experiment. Turn the timer to the shortest time setting, often labeled test. Fiddle with the sensitivity settings to find a setting that seems to be effective and mark this with a marker. Determine the angle at which it is effective—likely at around 120°. Find out how far a person can be from the unit and still set it off. Use a hairdryer or fan to determine what the response to wind is. Leave it in location that is alleged to NOT be haunted and monitor it for 12 hours to establish the intrinsic idiosyncrasies of the device.

Of course, a controlled environment is fine, but there is a great deal to be learned in the field. Case in point, during one of the Maine investigations the motion detector was triggered repeatedly. As it was later discovered, the window was improperly sealed (read: leaked like a sieve.) Lesson learned; we have avoided windows since. Another lesson, make sure the house pets (every last one of them) are in a secure location to minimize false positives.

But the biggest drawback is apparent on the Dark Man case. If the security camera monitoring the device does not show the entire field of view, its usefulness is greatly limited. Our solution to this was to create a camera trigger and leave a digital camera on a tripod with the motion detector during times when movement would be limited—such as deadtime. The camera controller can be found in the list of references. Anything of interest captured, so far? A lot of pictures featuring unsuspecting backsides. But we remain hopeful that something useful will come of it.

Additional References:
http://hyperphysics.phy-astr.gsu.edu/hbase/wien.html#c3

http://www.glolab.com/pirparts/infrared.html

http://www.murata.com/catalog/s21e5.pdf

http://lightdesigns.googlepages.com/camtroller
